zebex z-九游会登录

物理特征

尺寸:

18 cm h x 10.7cm l x 7 cm w

重量:

160g

工作电压和电流:

5 vdc /-10% @ 400 ma

性能

图像 (像素):

640 pixels (h)x 480 pixels (v)

光源:

aiming: 617 nm led; illumination: 6500k led

视角:

40° (h) x 26° (v)

转角，仰角，斜角:

360°, ±65°, ±60°

印刷对比度:

最低25% 的反射差

可识别条码

1-d:

upc/ean, upc/ean with supplementals, bookland ean, issn, ucc coupon extended code, code128, gs1-128, isbt 128, code 39, code 39 full ascii, trioptic code 39, code 32, code 93, code11, matrix 2 of 5, interleaved 2 of 5, discrete 2 of 5, codabar, msi, chinese 2 of 5, gs1 databar variants, korean 3 of 5, isbt concat

2-d:

pdf417, micropdf417, composite codes,data matrix, maxicode, qr code, microqr, aztec

运动容差:

最高可达每秒25英寸（63.5cm）

界面:

usb, rs232

环境参数

工作温度:

32° to 122° f / 0° to 50° c

存储温度:

-40° to 158° f / -40° to 70° c

湿度:

5% to 95%,无凝结

跌落/冲击规格:

可承受多次1.5m高处跌落至混凝土地面的冲击力

环境亮度:

荧光可达1600 lux.日光可达 86,000 lux.
