zebex z-5130

• world's smallest ccd scan module

• a "test" button on top for performance testing

• mounting holes at bottom for easy installation

• great ccd scanning performance and future upgradeability on firmware

技术参数

z-3151hs 技术参数

operational

light source optical system microprocessor depth of field scan rate minimum bar width print contrast indicators (led) beeper operation system interfaces	617 nm visible red led linear ccd array 32 bit 280 mm (ean-13 100%, pcs=90%) 330 scans per second 0.1 mm (0.07 mm actually); (code 39, pcs=90%) 30% @ upc/ean 100% “ok”, “ng”, “pwr” and “test” button programmable tone & beep time rs-232c, hid usb, usb – virtual com port emulation

physical

dimensions weight mounting	39.0 × 26.6 × 15.8 mm 15 g (cable excluded) 3-m 1.6 × 0.35 screw hole

power

input voltage operating current	5 vdc ±10% 120 ma typical

regulatory
emc	ce & fcc doc compliance, vcci, bsmi

environmental

operating temperature storage temperature humidity light levels	0°c – 50°c (32°f – 104°f) -20°c – 60°c (-4°f – 140°f) 20% – 95% rh (non-condensing) 0 – 100,000 lux
